OSP Laboratory small coating machine is Shijiazhuang Oslo School Machinery Limited company of science and technology independent design and development, combined with the current domestic coating industry in the new product market demand, to the enterprise research and development of new products and the laboratories in Colleges and universities, scientific research institutions to launch a high price than the product. Oslo School lab coater machine all adopt high quality accessories, the price is only half of the foreign similar product function the same, in terms of performance is not inferior to foreign products, the price is very high.

In the after-sales service, our company is to provide customers with lifelong maintenance of lifetime warranty service, for customers to avoid product after-sales service.

In product updates, in view of customer demand, and constantly introduce a variety of functional laboratory coating machines, and can be customized for the customer needs of a variety of laboratory coating machine.

In the market reaction: since the Oslo School Laboratory coater since listing promotion, many coating industry enterprises (such as papermaking, printing, film industry, the production of adhesive tape) R & D institutions, domestic well-known University Laboratory of favor.

Oslo School Laboratory coater with Oslo School (OSP) precision extrusion wire rod, break through the traditional scraper, steel wire scraping rod coating limit, with high precision, ultra-thin coating (minimum coating wet film can amount to 1.5um, at present the world up to the lowest amount of coating).

Use:

As the main factors affecting the film with coating speed and pressure in the coating device, etc., thus by artificial coating the coating often appear inconsistent, especially of differences between humans is bigger, this comparison between model test results difficult. The company's automatic film coating machine is designed to make the operator easily on different substrates coated with accurate wet film and carefully designed to greatly improve the accuracy of the film, the effectiveness of.

main parameter

The device uses a variable speed motor, precise control of coating speed. Through the MCU control speed and stability of the pressure to ensure that the coating effect, to ensure the uniformity and stability of the coating

1 coated base size: 570mm * 340mm

2 effective film size: long 430mm width 300mm

3 coating speed: 0 ~ 2cm/s stepless speed change

4 total power: 200W

5 power: 50Hz 220V

6 dimensions: 570mm * 340mm * 100mm * VB (L * w * h)

7 weight: about 20Kg

The 8 film thickness: Oswald faction (OSP) precision extrusion coating measuring stick coating film (the thin film wet film thickness 1.5um)

9 wire rod size diameter 1.0mm, length 400mm, effective coating width 300mm

Use operation instructions:

1 connect the power supply.

2 will be coated with the substrate (such as: black and white paper) flat on the base of the coating, and clamp.

3 the lateral push rod is arranged on the fixing rod on both sides of the coating base.

4 the film is placed in front of the lateral push rod.

5 adjust the speed control knob, select the appropriate coating speed.

6 directly in front of the film to put the right amount of coating.

7 press the "start" button and start coating.

8 to be coated after the stop, the remaining paint scraping waste collection disk.

9 was a good model for the next operation.

Matters needing attention：

1 the coating base should be kept clean and no debris stuck in the above, so as not to affect the brightness of the coating base, thereby affecting the next coating; if accidentally paint dripping in the coated base, should also be timely cleaning.

2 to determine the size of the coated substrate, the coating will be used to clamp the substrate, in order to improve the fixed effect.

3 after each use of the equipment, should be promptly cleaned waste.
